Midea Air Conditioner WALL 1.5HP R32 Non Inverter (MSXD12CRN8)

Midea MSXD12CRN8 Air Conditioner WALL 1.5HP R32 Non Inverter with Air Magic; Flash Cooling; Prime Guard; Triple Protection Screen

Indoor unit

Air flow (H) : 600(353) m3/h(cfm)

Indoor Sound level (H/L) : 41/30 dB(A)

Dimension(W*D*H) : 835x208x295 mm

Packing (W*D*H) : 905x355x290 mm

Net/Gross weight : 9.3/11.9 Kg

Refrigerant piping

Liquid side/ Gas sidemm(inch) : Φ6.35/Φ9.52(1/4″/3/8″)

Max. refrigerant pipe length : 20 m

Max. difference in level : 8 m

Outdoor unit

Outdoor Sound level : 52 dB(A)

Dimension(W*D*H) : 765x303x555 mm

Packing (W*D*H) : 887x337x610 mm

Net/Gross weight : 27.3/29.7 Kg

Refrigerant Charge : R32/430g

Design pressure : 4.3/1.7 MPa

Misc

Cooling Capacity : 12,000 Btu/h

Power consumption : 1053W

Running current : 4.58A

CSPF(Cooling seasonal performance factor) : 3.62Wh/Wh

Energy Efficiency Star Rating : 3

Power supply : 220-240V~,50Hz,1Ph (power supply to indoor) V,Hz,Ph

Indoor-Outdoor connection wiring (Not included) : 3×1.5 mm2

Power supply wiring(Not included wire) : 3×1.5 mm2

Thermostat type : Wireless Remote Control (Wifi control, Wire control optional)

CONSUMER MANUALS

https://www.midea.com/dam/jcr:6f47322a-70df-4d63-a2ba-b8aa8964889a/User%20Manual%20-%20MSXS,%20MSXD,MSXG.pdf
